Wontech

V LASER

V-Laser’s advanced combination of Long Pulsed KTP 532nm and Nd:YAG 1064nm laser platforms provides superior technology for the treatment of a range of vascular and pigment indications.

Features & Benefits

No Consumables

All Skin Types I-VI

Minimal Discomfort

Flexibly Adjusted

Better Results

Hair Removal

High ROI

Long-pulsed KTP 532nm and Nd:YAG 1064nm

For vascular lesions, pigmentation, skin rejuvenation and hair removal

V-Laser’s advanced combination of Long Pulsed KTP 532nm and Nd:YAG 1064nm laser platforms provides superior technology for the treatment of a range of vascular and pigment indications.

It sets high standards for the comfortable and efficient treatment of vascular lesions, dyschromia, pigmentation and skin rejuvenation.

V-Laser is particularly effective for treating deeper or thicker vascular lesions, including leg veins, venous lakes and periorbital veins, regardless of skin type.
Three different modes (532nm, 1064nm or Genesis) are available for various treatments without switching handpieces.

Energy, pulse duration and spot size can all be flexibly adjusted to provide targeted results.

• Vascular lesions

• Pigmented lesions

• Post-procedure bruising

• Skin rejuvenation

• Hair removal

• Pokliderma

• Leg veins

Variable Spot Sizes 2 to 12mm

Various spot sizes and repetition rates up to 3Hz in 532nm, 10Hz in 1064nm and 10Hz in Genesis mode.

Sapphire Chill Tip

V-Lasers handpiece is equipped with a sapphire chill tip which allows for comfortable patient treatments.

V-TONING

GENESIS MODE
For skin rejuvenation, use V-toning mode: 1064nm micropulse with 0.3ms.

BROWNS + REDS + REJUVENATION
8-12mm spot size beam works quickly to improve mixed component dyschromia, resulting in brighter, clearer skin. V-toning (Genesis mode), with short pulsed 0.3ms, treats the dermal layer with bulk heating to stimulate new collagen fibre growth and improve the appearance of wrinkles, texture and tone. Rosacea, redness and scars can all be improved with toning to brighten and smooth the skin texture.

532nm KTP

Spot: 2 - 12 mm - Fluence: 1.4 - 60J/cm2 - Pulse: 1.5 - 40 ms

It has 5 times greater affinity for oxyhaemoglobin than 595nm, giving improved results, more selective treatments and greater patient comfort. It is particularly effective for treating diffuse redness, cherry angiomas, telangiectasia, poikiloderma and port wine stains.

1064nm Nd:YAG

Spot: 2 - 12 mm - Fluence: 1.3 - 300J/cm2 - Pulse: 5 - 60 ms

Particularly effective for treating deeper or thicker vascular lesions, including leg veins, venous lakes and periorbital veins.

Micro Pulsed Nd:YAG

Spot: 2 - 12 mm      Fluence: 0.9 - 127J/cm2      Pulse: 0.3 ms

Targets micro-vascularity with microsecond high peak power pulse;

reducing erythema, while stimulating collagen production. It is particularly effective for treating diffuse redness, rosacea and scars.

Clinical Results
