PROCEDURE
01
Laser radiation
02
Collapsed
02
Collapsed
04
Pigments lesion removal
Beam Profile
Beam Shape: Top Hat Beam
It is possible to predict safe and effective treatment results through the uniform energy distribution of the beam profile.
250 PICO
HEXA MLA
HEXA MLA uses the principle of Laser Induced Optical Breakdown (LIOB)
Cavitation occurs in the target area (epidermis or dermis) and stimulates collagen and elastic fibers.
As cavitation is formed with preserving the stratum corneum layer intact, the recovery period is shorten and the effects of scar treatment and
skin rejuvenation are very satisfactory in a single session.
SYSTEM&ACC
Zoom H/P
532 & 1064nm
Collimation H/P
MLA H/P
532 & 1064nm
DOE H/P
532nm / 1064nm
DYE H/P
595nm / 660nm
SKIN TYPE
By combining 7 types of handpieces and 4 wavelength,
it is possible to perform treatments tailored to the patient’s skin type and skin concerns.
| Type 1 | Type 2 | Type 3 | Type 4 | Type 5 | Type 6 | |
|---|---|---|---|---|---|---|
| Freckles & Black spots | 532nm + Zoom H/P | |||||
| 660nm + DYE(595) H/P | ||||||
| Pigmentation | 1064nm + Zoom H/P | |||||
| 1064nm + Collimation H/P | ||||||
| Melisma | 1064nm + Zoom H/P | |||||
| 1064nm + Collimation H/P | ||||||
| Brightening | 1064nm + Zoom H/P | |||||
| 1064nm + Collimation H/P | ||||||
| Acne scars | 1064nm + MLA H/P | |||||
| Acne red marks | 595nm + DYE(660) H/P | |||||
| Pores | 1064nm + MLA H/P | |||||
| Skin texture improvement | 1064nm + MLA H/P | |||||
| 1064nm + DOE H/P | ||||||
| Tattoos | 1064nm + Zoom H/P | |||||
| Red tattoos | 532nm + Zoom H/P | |||||
| 595nm + DYE(660) H/P | ||||||
| Green tattoos | 660nm + DYE(595) H/P | |||||
SPECIFICATIONS
| System Type | Nd:YAG |
| Wavelength | 1064nm, 532nm |
| Output | 500mJ (1064nm), 250mJ (532nm) |
| Pulse Duration | 250ps |
| Peak Power | 1064nm: 2GW (@500mJ/250ps); 532nm: 1.3GW (@250mJ/190ps) |
| Spot Size | 2mm ~ 10mm (step 1mm) |
| Repetition Rate | Single, 1–10 Hz |
| Handpiece | Zoom H/P, Collimation H/P, MLA H/P, DOE (532nm, 1064nm) H/P, DYE (595nm, 660nm) H/P |
CLINICAL DATA
